Name: DeviceLab Audiophile
Author: STRATEGIA-X

Question 1

Is DeviceLab Audiophile free to use?

Accepted Answer

Yes, DeviceLab Audiophile is completely free. All 27 measurement instruments — oscilloscope, spectrum analyzer, spectrogram, THD analyzer, room acoustics, impedance analyzer, frequency/noise generators, speaker tests, and export tools — are available at no cost with no in-app purchases or premium tiers.

Question 2

What Android version and hardware do I need?

Accepted Answer

DeviceLab Audiophile requires Android 7.0 (Nougat, API 24) or higher and targets Android 15 (SDK 36). The app is lightweight at ~15MB. A phone with a decent microphone is sufficient for most measurements. For professional-grade accuracy, use an external USB calibrated microphone.

Question 3

How accurate are the measurements compared to professional equipment?

Accepted Answer

Accuracy depends primarily on your device's microphone quality. Built-in phone microphones are suitable for relative measurements, trend analysis, and comparative testing. For absolute accuracy (especially SPL readings), calibrate the app using the Calibration System with a known reference source. External USB microphones significantly improve measurement quality.

Question 4

Does the app record or transmit my audio?

Accepted Answer

No. All audio processing happens 100% on-device in real-time. Microphone input is analyzed and immediately discarded — it is never recorded to disk unless you explicitly export a measurement. There are no cloud uploads, no remote processing, and no audio surveillance of any kind.

Question 5

What is THD and why does it matter?

Accepted Answer

THD (Total Harmonic Distortion) measures the ratio of unwanted harmonic content to the fundamental frequency, expressed as a percentage. Lower THD means cleaner audio reproduction. THD < 0.1% is considered excellent for audio equipment. The THD Analyzer also measures THD+N (including noise), SINAD (signal-to-noise and distortion ratio), and ENOB (effective number of bits) — all critical metrics for evaluating DAC/ADC and amplifier quality.

Question 6

How do I measure room acoustics?

Accepted Answer

Open the Room Acoustics Analyzer and tap Measure. A 3-second countdown starts, then 'CLAP NOW' appears. Produce a sharp, loud clap or snap. The app captures the room's impulse response over 3 seconds and calculates RT60 (reverberation time), EDT (early decay time), C50 (speech clarity), C80 (music clarity), and an overall room quality rating. Position yourself in the center of the room for the most representative measurement.

Question 7

What are the 5 noise colors and when should I use each?

Accepted Answer

White noise has equal energy at every frequency — used as a reference signal. Pink noise has equal energy per octave (1/f spectrum) — the standard for speaker calibration and room measurement. Brown noise emphasizes low frequencies (1/f²) — good for masking environmental sounds. Blue noise increases with frequency — useful for treble testing. Violet noise has strong high-frequency content (1/f³) — for ultra-high frequency analysis.

Question 8

How do I calibrate the decibel meter for accurate SPL readings?

Accepted Answer

Open the Calibration System and select SPL Reference Calibration. Enter the known dB level of your reference source (professional calibrators output 94 dB or 114 dB). The app records the reference and applies the offset to all future SPL measurements. Without calibration, the decibel meter shows relative levels — accurate for comparing measurements but not for absolute SPL values.

Question 9

What FFT size should I use?

Accepted Answer

FFT size controls the tradeoff between frequency resolution and update speed. 512–1024: Fast updates, coarse frequency resolution (~43–86 Hz per bin). Good for real-time monitoring. 2048–4096: Balanced — the default. 8192–16384: Maximum frequency resolution (~2.7–5.4 Hz per bin) but slower updates. Best for THD analysis and precise frequency identification. At 44100 Hz sample rate, bin width = 44100 / FFT size.

Question 10

Can I use this for speaker building / driver characterization?

Accepted Answer

Yes — DeviceLab Audiophile includes tools specifically for speaker builders. The Impedance Analyzer measures impedance vs. frequency and calculates Thiele-Small parameters (Fs, Qms, Qes, Qts, Vas). The Polarity & Phase Analyzer verifies wiring correctness. The Speaker Test provides channel isolation, frequency point tests, and polarity pulse verification. The CSD (Cumulative Spectral Decay) reveals driver resonances and cabinet colorations.

Question 11

What's the difference between the Oscilloscope and Spectrum Analyzer?

Accepted Answer

The Oscilloscope shows audio as a waveform in the time domain — voltage vs. time. It reveals waveform shape, frequency, period, and amplitude. The Spectrum Analyzer shows audio in the frequency domain — magnitude vs. frequency using FFT. It reveals which frequencies are present and their relative strengths. Use the oscilloscope for waveform inspection and the spectrum analyzer for frequency content analysis.

Question 12

How does Bluetooth latency testing work?

Accepted Answer

The Bluetooth Latency Analyzer detects your connected Bluetooth codec (SBC, AAC, aptX, LDAC, etc.) and provides an estimated codec latency based on known specifications. It also performs a round-trip latency measurement with confidence scoring. SBC typically has ~200ms latency, aptX ~80ms, and aptX Low Latency ~40ms. Latency below 40ms is generally acceptable for video synchronization.

Question 13

What export formats are available for measurements?

Accepted Answer

Three export formats are supported: CSV with proper headers (Type, Title, Subtitle, Timestamp, Data) for spreadsheet analysis; PDF with professional formatting, app branding, and website footer for reports and documentation; and plain text for quick sharing via email or messaging. Bulk export generates all measurements in a single file. PDF bulk export shows 2 measurements per page with a summary title page.

Question 14

Why does the RT60 rating say my room is 'Dead' or 'Very Reverberant'?

Accepted Answer

RT60 classifications: Dead (<0.3s) means excessive absorption with no liveliness — add reflective surfaces. Dry (0.3–0.5s) is good for vocal recording. Ideal for speech (0.5–0.8s) is optimal for conference rooms and lecture halls. Ideal for music (0.8–1.2s) suits concert halls and listening rooms. Reverberant (1.2–2.0s) may need acoustic treatment. Very Reverberant (>2.0s) indicates a highly reflective space — common in empty rooms with hard surfaces.

Question 15

Can I use the Frequency Generator as a hearing test?

Accepted Answer

The Frequency Generator produces tones from 20 Hz to 20 kHz, which covers the full human hearing range. While not a medical audiometer, you can use it informally to identify the highest frequency you can hear (which decreases with age) and test for frequency-specific hearing sensitivity. Play tones at various frequencies at low volume and note where you stop hearing them.

Question 16

What does A-weighting mean in the Spectrum Analyzer and SPL Meter?

Accepted Answer

A-weighting is a frequency filter that approximates human hearing sensitivity. Humans are less sensitive to very low and very high frequencies compared to mid-range (1–4 kHz). A-weighting reduces the contribution of low frequencies (<500 Hz) and very high frequencies (>6 kHz) to match perceived loudness. It's the standard weighting for noise exposure regulations, environmental noise measurement, and general-purpose SPL readings. C-weighting is flatter and better suited for music and low-frequency content.
